☆ HDMI2.0b, USB 2.0, HDCP 2.2 / 1.x and DVI 1.0 compliant
☆ Support 18Gbps video bandwidth
☆ Support video resolution up to 4k2k@60Hz YUV 4:4:4
☆ High bit rate audio transmission via HDMI
☆ The transmission distance can be extended up to 70m / 230ft at the resoution of 1080P@60Hz, or 40m / 164ft at 4K2K@60Hz 4:4:4 via a single CAT6/6a cable
☆ Support USB signal, bi-directional IR and RS-232 control signal passthrough
☆ Transmitter supports de-embeded audio for digital optical and analog audio output.
☆ Support USB KVM function
☆ Support POC (Power over Cable) function
☆ Compact design for easy and flexible installation
| Technical | |||
| HDMI Compliance | HDMI 2.0b | ||
| HDCP Compliance | HDCP 2.2/1.x | ||
| Video Bandwidth | 18Gbps | ||
| Video Resolution | Up to 4K2K@60Hz YUV 4:4:4 | ||
| USB Compliance | USB 2.0 | ||
| USB Transfer Rate |
Transmission rate up to 480mb/s, USB1.1 compliant |
||
| Transmission Distance | 70m via a single CAT6 cable | ||
| Color Space | RGB, YCbCr 4:4:4, YCbCr 4:2:2 | ||
| Color Depth |
8-bit, 10-bit, 12-bit (1080P@60Hz) 8-bit (4K2K@60Hz YUV4:4:4) 8-bit, 10-bit, 12-bit (4K2K@60Hz YCbCr 4:2:2/4:2:0) |
||
| HDR | HDR10, HDR10+, HLG | ||
| HDMI Audio Format |
HDMI: LPCM 2/5.1/7.1CH, Dolby Digital, DTS 5.1, Dolby Digital+, Dolby TrueHD, DTS-HD Master Audio, Dolby Atmos, DTS:X Optical: Dolby Digital, DTS 5.1, PCM 2CH Analog Signal: LPCM 2CH |
||
| Connections | |||
| Transmitter |
Input: 1x HDMI IN [TypeA, 19-pin female] 1x IR IN [3.5mm Stereo Mini-jack] 1x Service [Micro-USB jack] 1x USB [USB-B, 4-pin female] Output: 1x HDBaseT OUT [RJ45] 1x IR OUT [3.5mm Stereo Mini-jack] 1x L/R OUT [3.5mm Stereo Mini-jack] 1x SPDIF OUT 1x RS-232 [Phoenix jack] |
||
| Receiver |
Input: 1x HDBaseT IN [RJ45 with light] 1x IR IN [3.5mm Stereo Mini-jack] 1x Service [Micro-USB jack] Output: 1x HDMI OUT [TypeA, 19-pin female] 1x RS-232 [Phoenix jack] 1x IR OUT [3.5mm Stereo Mini-jack] 2x USB [USB-A, 4-pin female] |
||
| Mechanical | |||
| Housing | Metal Enclosure | ||
| Color | Black | ||
| Dimensions | 165mm [W]×88.3mm [D]×20mm [H] | ||
| Weight | 165g | ||
| Power Supply |
DC 24V/1A; Support POC function |
||
| Power Consumption | 13W (max) | ||
| Operation Temperature | 32°F - 104°F / 0°C - 40°C | ||
| Storage temperature | -4°F - 140°F / -20°C - 60°C | ||
| Relative Humidity |  20 - 90% RH (no condensation) |
||
