☆ HDMI 2.1 and HDCP 2.3 compliant
☆ Support 40Gbps video bandwidth
☆ Support video resolution up to 8K@60Hz 4:2:0 10bit, 8K@30Hz 4:4:4 10bit, 4K@120Hz 4:4:4 10bit
☆ VRR, FVA, ALLM supported
☆ Support HDR, HDR10, HDR10+, Dolby Vision, HLG pass through
☆ Support HDMI audio formats: LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD
☆ 2x2 Switch with Dual Output
☆ Built-in Equalizer, Retiming and Driver
☆ Advanced EDID management
☆ Support IR remote control and front panel button switching
☆ Compact design for easy and flexible installation
| Technical | ||||
| HDMI Compliance | HDMI 2.1 | |||
| HDCP Compliance | HDCP 2.3 | |||
| Video Bandwidth | 40Gbps | |||
| Video Resolution | Up to 8K@60Hz 4:2:0 10bit, 8K@30Hz 4:4:4 10bit, 4K@120Hz 4:4:4 10bit | |||
| Color Depth | 8/10/12-bit | |||
| Color Space | RGB, YCbCr 4:4:4 / 4:2:2. YUV 4:2:0 | |||
| HDMI Audio Formats |
LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX,DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD |
|||
| ESD Protection | Human body model—±8kV (Air-gap discharge) &±4kV (Contact discharge) | |||
| Connections | ||||
| Input | 2x HDMI IN [Type A, 19-pin female] | |||
| Output | 2x HDMI OUT [Type A, 19-pin female] | |||
| Control | 1x SERVICE [Micro USB, Update port] | |||
| Mechanical | ||||
| Housing | Metal Enclosure | |||
| Silkscreen Color | Black | |||
| Dimensions | 145mm (W) x 68mm (D) x 17mm (H) | |||
| Weight | 265 g | |||
| Power Supply | Input: AC100 - 240V 50/60Hz, Output: DC 5V/2A (US/EU standards, CE/FCC/UL certified) |
|||
| Power Consumption | 6.15 W (Max) | |||
| Operation Temperature | 32°F - 104°F / 0°C - 40°C | |||
| Storage temperature | -4°F - 140°F / -20°C - 60°C | |||
| Relative Humidity |  20 - 90% RH (no condensation) |
|||
| Recommended HDMI Cable | ||||
| Video Resolution | 8K | 4K60 | 4K24 | 1080P |
| HDMI Cable Type | Ultra HDMI 2.1 | HDMI 2.0 | HDMI 1.4 | HDMI 1.4 |
| HDMI Cable Length (HDMI IN / OUT) |
3m/10ft | 8m/26ft | 12m/39ft | 15m/49ft |
| The use of “Premium High Speed HDMI” cable is highly recommended. |
||||
