Panel
| Screen Size | 30" |
|---|---|
| Panel Technology | OLED |
| Aspect Ratio | 16 : 9 |
| Native Resolution | 1,366 × 768 (HD) |
| Brightness | 200 / 600 nit (APL 100% / 25%, without Glass) |
| Contrast Ratio | 200,000 : 1 |
| Dynamic CR | No |
| Color gamut | BT709 110% |
| Viewing Angle (H x V) | 178 × 178 |
| Color Depth | 10 bit (R), 1.07 Billion Colors |
| Response Time | 0.1 ms (G to G), 8 ms (MPRT) |
| Refresh Rate | 120 Hz |
| Surface Treatment (Haze) | Hard Coating 5 H, Haze 3% (Set) |
| Lifetime | 30,000 Hrs (Typ.) |
| Operation Hours (Hours / Days) | 18 / 7 (Moving Content Only) |
| Portrait / Landscape | Yes / Yes |
| Transparency (Typ.) | 37% (Set) |
| QWP (Quarter Wave Plate) | No |
Mechanical Specification
| Bezel Color | Transparent |
|---|---|
| Bezel Width | 7.9 / 7.9 / 7.9 / 114.7 mm (T/R/L/B) |
| Weight (Head) | 4.2 kg (Head), 2.4 kg (Signage Box) |
| Packed Weight | 10.1 kg |
| Monitor Dimensions (W × H × D) | 680.2 × 496.2 × 15.3 mm (Head), 449.2 × 288.6 × 42.8 mm (Signage Box) |
| Carton Dimensions (W × H × D) | 826 × 593 × 195 mm |
| Protection Glass (Thickness) | 3.0 mm |
| Protection Glass (Tempered / Chemical Strengthening) | Chemical Strengthening |
| Protection Glass (Anti-Reflective) | Yes (AR+AF Coating) |
| Protection Glass (Shatter-Proof) | Yes |
Feature
| Key Feature | Internal Memory (eMMC (16 GB)), Temperature Sensor, webOS23, Local Contents Scheduling, Group Manager, USB Plug & Play, Fail Over, RS-232C Sync, Local Network Sync, Video Tag (4), Screen Rotation, Gapless Playback, Setting Data Cloning, SNMP, ISM Method, Status Mailing, Control Manager, PM Mode, Wake on LAN, HDMI-CEC, SI Server Setting |
|---|
Environment Conditions
| Operation Temperature | 0 to 40 |
|---|---|
| Operation Humidity | 10%-80% |
Power
| Power Supply | AC 100-240 V~, 50/60 Hz |
|---|---|
| Power Type | Built-in Power |
Power Consumption
| Typ./Max. | 45 W (IEC 62087) / 86 W |
|---|---|
| DPM | 0.5 W |
| Power off | 0.5 W |
| BTU (British Thermal Unit) | 154 BTU/Hr (Typ.), 294 BTU/Hr (Max.) |
Standard (Certification)
| Safety | CB / NRTL |
|---|---|
| EMC | FCC Class "A" / CE / KC |
| ErP | Yes |
Software Compatibility
| SuperSign CMS, SuperSign Control+, SuperSign Cloud, Mobile CMS, LG ConnectedCare |
Connectivity
| Input | HDMI (HDCP 2.2/1.4), DP (HDCP 1.3), RS-232C, RJ45 (LAN), IR (External IR Receiver), USB (USB 2.0 Type A) |
|---|---|
| Output | DP, Audio, Touch USB (USB 2.0 Type B), RS-232C, RJ45 (LAN), IR (Sharing RS-232C) |
Language
| English, French, German, Spanish, Italian, Korean, Chinese (Simplified), Chinese (Original), Portugues (Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues (Europe), Dutch, Czech, Greek, Polski, Türkçe, Arabic |
Accessory
| Basic | Remote Controller, Power Cord, QSG, IR Receiver, Regulation Book, Phone to RS-232C Gender, MCX / Harness Cables (3 m × 4 ea / 3 m × 2 ea for Connection between Panel and Signage Box), HDMI Cable (3 m), Micro to A Type USB Cable (3 m, for Connection between Touch and Signage Box), A to B Type USB Cable (Touch Out), Screw (M4 × L22, 12 ea / M4 Nut 12 ea / M3 × L5.5 (Silver), M3 × L5.5 (Black) 8 ea / Shield Cover Assy, Rubber Damper 4 ea, Touch Cable Holder 2 ea, MCX Cable Holder 2 ea |
|---|
Special Feature
| Conformal Coating (Power Board) | Yes |
|---|
Touch
| Available Object Size for Touch | Ø8 mm ↑ |
|---|---|
| Response Time | 100 ms ↓ |
| Accuracy | 2 mm |
| Interface | USB 2.0 |
| Protection Glass Thickness | 3.0 T (Anti-Glare / Anti-Finger Print) |
| Protection Glass Transmission | 85% (Typ.) |
| Operating System Support | Windows 10/11 |
| Multi Touch Point | Max. 10 Points |
