| Rated Power : 360W |
| Mic Input : -60dB, 600Ω, unbalanced, 6.3mm TS port |
| Aux Input : -20dB, 10Ω, unbalanced, Stereo RCA port |
| Aux Output : 0dB, 600Ω, unbalanced, Stereo RCA port |
| Speaker Output : High Impedance: 100V; Low Impedance: 8Ω; |
| Volume Control for Each Zone : 6 zones speaker output with individual volume control; Note: the power capacity for each zone can reach the rated the power of amplifir. But make sure that the total power of zone 1~6 can not exceed the rated power. |
| Protection : AC fuse, overheating, overvoltage, overcurrent, short, DC, and muting during power on protections. |
| EQ for Master Output : Treble: ± 12dB at 10kHz; Bass: ± 12dB at 100Hz |
| Frequency Response : 20~20kHz (±3dB) |
| S/N : AUX input>80dB |
| T.H.D : <0.5% at 1kHz, at1/3 rated power. |
| Power Source : 220~240VAC, 50/60Hz |
| Power Consumption : 500W at rated power |
| Temperature / Humidity : -10°C ~ +40°C, <95% |
| Weight : 14kg |
| Dimensions : 482(W) x 88(H) x 350(D) mm |
| Shipping Weight : 16kg |
| Shipping Dimensions : 0.0382CBM, 58(W) x 47(H) x14(D) cm |
